ALL IN ONE Rechargeable Battery Lifepo4 32650 12V 7Ah Battery Pack

2021-06-07 01:06




Características electricas

Voltaje nominal12.8v
Capacidad nominal7Ah @ 0.2C
Resistencia interna ≤90mΩ
Ciclo de vida>2000 cycles @ 0.2c charge/ discharge at 100%DOD,End of life 70% capacity
Months Self discharge≤3.5% por mes a 25 ℃


Cargo estándar

Voltaje de carga14,6 ± 0,2 V
Charge Mode( CC/CV)At 0℃~45℃ temperature, charged to 14.6v at constant current of 0.2C5A, and then, changed continuously with constant voltage of 14.6v until the current was not more than 0.02C5A
Corriente de carga1.4A
Max.Charge current3,5 A


Descarga estándar

Corriente de descarga1.4A
Max.continuous current7A
Max. Pulse current20A (<3S)
Voltaje de corte de descarga10.0V



Temperatura de carga0℃ to 45 ℃
Temperatura de descarga-20℃ to 60 ℃
Temperatura de almacenamiento0℃ to 45 ℃
Resistencia al polvo de aguaIP55



Cell & MethodIFR26650 N35,4S2P
Plastic Caseabdominales
Dimension (L*W*H*TH)151*65*94*100mm
PesoApprox. 1.06KG


1. Safety: safest Lithium battery, CE UL approved, built-in PCM/BMS
2. Energía limpia y verde, sin material tóxico contenido
3. Long life cycle:> 2000 times, 6-8 times of lead acid battery
4. No memory effect, highly efficient, charge anytime
5. Small size and light weight: 1/2 size& weight of lead acid battery
6. Good performance at high temperature
7. Low self-discharge rate: < 3% monthly

Advantages for ALL IN ONE Lithium Iron Battery

Energy density is high The volume and weight of lithium battery is 1/3 to 1/4 of the traditional lead acid battery with the same capacity.
Energy conversion rate is 15% higher than that of a traditional lead acid battery, the advantage of energy saving is obvious. Self-discharge rate < 2% per month.

Broad temperature adaptability Products perform well at a temperature of -20°C to 60°C, without air conditioning system.

Cycle durability for a single cell is 2000 cycles 100% DOD, which is 3 to 4 times more than the cycle durability of a traditional lead acid battery.

Higher discharge rate, faster charging and discharging When there is a need for backup power supply for a period of 10 hours or less, we could reduce up to 50% of the capacity configuration, comparing to lead acid battery.

High security Our lithium battery is safe, electrochemical materials are stable, no fire or explosion under  extreme conditions such as high temperature, short circuit, drop impact, piercing, etc


Electric Vehicles,electric mobility

Solar/wind energy storage system

UPS, backup power


Medical equipment

Lighting and so on

Nuestra fábrica

Why Choose ALL IN ONE?
1) Nearly 11 years leading manufacturer,established in 2010. Factroy size: 10000 square meter
2) Strict management system and quality control, 100% inspection.Factories are satisfied with ISO 9001 & ISO
14001, products with CE/RoHS/TLC etc approval.
3) A professional experienced team to provide you high-quality service.All enquires will be replied in 24 hours.
4) Competitive price help you  to occupy more market share
5) 20000KWH production capacity to guarantee the best deliver time
6) 1-3 years warranty policy, up to now, our product defective rate is under 0.4%.

Empaque y envío

Preguntas más frecuentes

P: ¿Es usted una empresa comercial o un fabricante?
R: Estamos TODOS EN UNA sola fábrica original.

P: ¿Puedo tener muestras para probar? ¿Y cuál es el plazo de entrega para el pedido de muestra?
R: Sí, podemos suministrar muestras, el plazo de entrega de las muestras es de 3-5 días y el comprador paga el costo de la muestra y el costo de envío.

P: ¿Ofrecen servicio postventa?
R: Sí, la garantía es de 12 meses, si hay algún problema de calidad de nuestro lado en este período, podemos enviar uno nuevo como reemplazo.

P: ¿Acepta OEM / ODM?
R: Sí, está disponible.

P: ¿Tiene la capacidad real de la batería?
R: Todas nuestras celdas de batería son de Grado A, 100% nuevas y con capacidad real.

P: ¿Qué tipo de certificados tiene?
R: Podemos proporcionar CE, ROHS, FCC, IEC62133, MSDS, UN38.3 si la cantidad de su pedido es grande.

P: ¿tienes MOQ?
R: No limitado. También se aceptan pedidos pequeños. Más cantidad tiene un mejor precio, comprobaremos el mejor precio para usted.

P: ¿Cuál es su plazo de pago?
A: We adopt T/T and Paypal payment way and so on.

Nota: We are a battery manufacturer. All products do not support retail, please contact us for product prices!
